Shaft-Specifications

All data at a glance

Shaft Metric [mm] Imperial [inch] GPI Bushing
[grain]
Deflection ATA
Spine
[pound]
Length OD ID Str. +/- Length OD ID Str. +/- ASTM ATA
Agnis 1416 838.20 5.56 4.74 0.076 33″ 0.219″ 0.187″ 0.003″ 7.3 1.3 1.657″ 1.367″ 19.0
Agnis 1516 838.20 5.95 5.14 0.076 33″ 0.234″ 0.202″ 0.003″ 7.9 3.0 1.313″ 1.083″ 24.0
Agnis 1616 838.20 6.35 5.54 0.076 33″ 0.250″ 0.218″ 0.003″ 8.5 4.3 1.040″ 0.858″ 30.3
Agnis 1716 838.20 6.75 5.93 0.076 33″ 0.266″ 0.234″ 0.003″ 8.8 6.0 0.868″ 0.716″ 36.3
Agnis 1816 838.20 7.14 6.33 0.076 33″ 0.281″ 0.249″ 0.003″ 9.2 6.0 0.728″ 0.601″ 43.3
Agnis 1916 838.20 7.54 6.73 0.076 33″ 0.297″ 0.265″ 0.003″ 9.8 8.5 0.652″ 0.538″ 48.3
Agnis 2016 838.20 7.94 7.12 0.076 33″ 0.313″ 0.281″ 0.003″ 10.3 12.6 0.520″ 0.430″ 60.5
Agnis 2116 838.20 8.33 7.52 0.076 33″ 0.328″ 0.296″ 0.003″ 10.8 15.0 0.456″ 0.377″ 69.0
Agnis 2216 838.20 8.73 7.92 0.076 33″ 0.344″ 0.312″ 0.003″ 11.6 17.5 0.406″ 0.335″ 77.6

  • Shafts in aluminium alloy ENAW 7001-T6
  • Shafts are dolphingrey anodized
  • Bushing with nock-drilling 4,22 mm / 1/6 inch, factory mounted

Shaft Metric [mm] Imperial [inch] GPI Deflection ATA
Spine
[pound]
Length OD ID Str. +/- Length OD ID Str. +/- ASTM ATA
Mantis 750 838.20 7.87 6.25 0.152 33″ 0.310″ 0.246″ 0.006″ 11.7 0.750″ 0.619″ 42.0

  • Shafts made out of 100% high-performance fiberglas-prepregs
  • Black varnished surface
  • Weight tolerance +/- 2.0 grains (basis 28″)

Shaft Metric [mm] Imperial [inch] GPI Deflection ATA
Spine
[pound]
Length OD ID Str. +/- Length OD ID Str. +/- ASTM ATA
Trios X 500 838.20 7.30 6.25 0.152 33″ 0.287″ 0.246″ 0.006″ 7.7 0.500″ 0.413″ 63.0

  • Shafts made out of  50% high-performance fibreglas-prepegs and 50% carbon-prepregs
  • Finished black natural
  • Weight tolerance +/- 2.0 grains (basis 28″)

Shaft Metric [mm] Imperial [inch] GPI Deflection ATA
Spine
[pound]
Length OD ID Str. +/- Length OD ID Str. +/- ASTM ATA
Agil 300 838.20 7.55 6.25 *** 33″ 0.297″ 0.246″ *** 8.4 0.300″ 0.248″ 105.0
Agil 400 838.20 7.40 6.25 *** 33″ 0.292″ 0.246″ *** 7.3 0.400″ 0.330″ 78.7
Agil 500 838.20 7.21 6.25 *** 33″ 0.284″ 0.246″ *** 6.1 0.500″ 0.413″ 63.0
Agil 600 838.20 7.14 6.25 *** 33″ 0.281″ 0.246″ *** 5.6 0.600″ 0.495″ 52.5
Agil 700 838.20 7.07 6.25 *** 33″ 0.279″ 0.246″ *** 5.1 0.700″ 0.578″ 45.0

  • Shafts made out of 100% carbon-prepregs
  • Finished black natural
  • *** Straightness 0.152 mm / 0.006 inch, weight tolerance +/- 2.0 grains (basis 28″)
  • *** Straightness 0.076 mm / 0.003 inch, weight tolerance +/- 1.0 grain (basis 28″)
  • *** Straightness 0.025 mm / 0.001 inch, weight tolerance +/- 0.5 grain (basis 28″)

Shaft Metric [mm] Imperial [inch] GPI Deflection ATA
Spine
[pound]
Length OD ID Str. +/- Length OD ID Str. +/- ASTM ATA
Mako 350 838.20 6.28 4.19 0.152 33″ 0.248″ 0.165″ 0.006″ 10.2 0.350″ 0.289″ 90.0
Mako 400 838.20 6.08 4.19 0.152 33″ 0.239″ 0.165″ 0.006″ 9.1 0.400″ 0.330″ 78.7
Mako 500 838.20 5.92 4.19 0.152 33″ 0.233″ 0.165″ 0.006″ 8.2 0.500″ 0.413″ 63.0
Mako 600 838.20 5.73 4.19 0.152 33″ 0.226″ 0.165″ 0.006″ 7.2 0.600″ 0.495″ 52.5
Mako 700 838.20 5.60 4.19 0.152 33″ 0.220″ 0.165″ 0.006″ 6.5 0.700″ 0.578″ 45.0
Mako 800 838.20 5.50 4.19 0.152 33″ 0.217″ 0.165″ 0.006″ 5.9 0.800″ 0.660″ 39.4
Mako 900 838.20 5.39 4.19 0.152 33″ 0.212″ 0.165″ 0.006″ 5.4 0.900″ 0.743″ 35.0
Mako 1000 838.20 5.35 4.19 0.152 33″ 0.211″ 0.165″ 0.006″ 5.2 0.1000″ 0.825″ 31.5
Mako 1100 838.20 5.28 4.19 0.152 33″ 0.208″ 0.165″ 0.006″ 4.8 0.1100″ 0.908″ 28.6
Mako 1300 838.20 5.20 4.19 0.152 33″ 0.205″ 0.165″ 0.006″ 4.3 0.1300″ 1.073″ 24.2

  • Shafts made out of 100% carbon-prepregs
  • Finished black natural
  • Weight tolerance +/- 2.0 grain (basis 28″)

Shaft Metric [mm] Imperial [inch] GPI Deflection ATA
Spine
[pound]
Length OD ID Str. +/- Length OD ID Str. +/- ASTM ATA
Oryx 350 838.20 6.28 4.19 *** 33″ 0.248″ 0.165″ *** 10.2 0.350″ 0.289″ 90.0
Oryx 400 838.20 6.08 4.19 *** 33″ 0.239″ 0.165″ *** 9.1 0.400″ 0.330″ 78.7
Oryx 500 838.20 5.92 4.19 *** 33″ 0.233″ 0.165″ *** 8.2 0.500″ 0.413″ 63.0
Oryx 600 838.20 5.73 4.19 *** 33″ 0.226″ 0.165″ *** 7.2 0.600″ 0.495″ 52.5
Oryx 700 838.20 5.60 4.19 *** 33″ 0.220″ 0.165″ *** 6.5 0.700″ 0.578″ 45.0
Oryx 800 838.20 5.50 4.19 *** 33″ 0.217″ 0.165″ *** 5.9 0.800″ 0.660″ 39.4
Oryx 900 838.20 5.39 4.19 *** 33″ 0.212″ 0.165″ *** 5.4 0.900″ 0.743″ 35.0
Oryx 1000 838.20 5.35 4.19 *** 33″ 0.211″ 0.165″ *** 5.2 0.1000″ 0.825″ 31.5
Oryx 1100 838.20 5.28 4.19 *** 33″ 0.208″ 0.165″ *** 4.8 0.1100″ 0.908″ 28.6
Oryx 1300 838.20 5.20 4.19 *** 33″ 0.205″ 0.165″ *** 4.3 0.1300″ 1.073″ 24.2

  • Shafts made out of 100% carbon-prepregs
  • Finished black natural
  • *** Straightness 0.152 mm / 0.006 inch, weight tolerance +/- 2.0 grains (basis 28″)
  • *** Straightness 0.076 mm / 0.003 inch, weight tolerance +/- 1.0 grain (basis 28″)
  • *** Straightness 0.025 mm / 0.001 inch, weight tolerance +/- 0.5 grain (basis 28″)

Shaft Metric [mm] Imperial [inch] GPI Deflection ATA
Spine
[pound]
Length OD ID Str. +/- Length OD ID Str. +/- ASTM ATA
Uhyre 400 838.20 5.62 4.19 *** 33″ 0.222″ 0.165″ *** 6.9 0.400″ 0.330″ 78.7
Uhyre 450 838.20 5.55 4.19 *** 33″ 0.219″ 0.165″ *** 6.4 0.450″ 0.371″ 70.0
Uhyre 500 838.20 5.44 4.19 *** 33″ 0.215″ 0.165″ *** 6.0 0.500″ 0.413″ 63.0
Uhyre 550 838.20 5.40 4.19 *** 33″ 0.213″ 0.165″ *** 5.6 0.550″ 0.454″ 57.3
Uhyre 600 838.20 5.34 4.19 *** 33″ 0.210″ 0.165″ *** 5.3 0.600″ 0.495″ 52.5
Uhyre 650 838.20 5.29 4.19 *** 33″ 0.208″ 0.165″ *** 5.0 0.650″ 0.537″ 48.5
Uhyre 700 838.20 5.27 4.19 *** 33″ 0.207″ 0.165″ *** 4.8 0.700″ 0.578″ 45.0
Uhyre 750 838.20 5.18 4.19 *** 33″ 0.204″ 0.165″ *** 4.5 0.750″ 0.619″ 42.0
Uhyre 800 838.20 5.17 4.19 *** 33″ 0.204″ 0.165″ *** 4.5 0.800″ 0.660″ 39.4

  • Shafts made out of 100% high-modulus carbon-prepregs
  • Finished black natural
  • *** Straightness 0.076 mm / 0.003 inch, weight tolerance +/- 1.0 grain (basis 28″)
  • *** Straightness 0.025 mm / 0.001 inch, weight tolerance +/- 0.5 grain (basis 28″)

NEXXXUS™ Indoor Shaft

NEXXXUS™ is our World Archery (FITA) conform 23/64″ indoor hybrid arrow shaft with maximum outer diameter of 9.30 mm in spines 300, 350, 400, 500, 600 and 700. Progress of our NEXXXUS™-Project below.

More informations soon here or on our Facebook Wall.

Progress of Project

Design 100%
Tests 90%
Final Tests 0%
Marketing 20%
To market launch 95%

NEVADA™ Indoor Shaft

NEVADA™ is our National Field Archery Association (NFAA) conform 27/64″ indoor all carbon arrow shaft in maximum outer diameter of 10.71 mm in spines 250, 300 and 350. Progress of our NEVADA™-Project below.

More informations soon here or on our Facebook Wall.

Progress of Project

Design 10%
Tests 100%
Final Tests 100%
Marketing 0%
To market launch 0%

Aurel Archery reserves the right to make variations without prior notice to the descriptions and informations in this website, in brochures, catalogs and other textual documents in the course of technical progress regarding texture, color, weight, measurements, design or other features.
Deflection measured in accordance to ASTM F2031-05 (2010), average value. ATA Spine Basis 26″
Straightness measured in accordance to ASTM F1889-05 (2010)
